• 2-MP 1/2.8" CMOS image sensor, low luminance, and high definition image • Outputs max. 2 MP (1920 × 1080)@25/30 fps • H.265 codec, high compression rate, ultra-low bit rate • Built-in warm light/IR LED, the max. illumination distance is 30 m and the max. warm light distance is 30 m • ROI, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments • Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes • Intelligent monitoring: Intrusion, tripwire (the two functions support the classification and accurate detection of vehicle and human) • Supports max. 256 G Micro SD card; built in MIC • 12 VDC/PoE power supply, easy for installation • IP67 protection • SMD Plus |
Series Overview
With advanced deep learning algorithm, Dahua WizSense 2 Series network camera supports intelligent functions, such as perimeter protection and smart motion detection. With starlight technology, this series camera provides a better image effect in the condition of low illuminance
Functions
Smart Dual Light
Dahua Smart Dual Light technology adopts smart algorithm to detect targets. Usually, the IR illuminator is on at night; when the target appears in the monitoring area, the white light is on, and the camera records the full-color video and information of key events. That is, the camera links snapshot and video with full-color image. When the target is out of the monitoring area, the white light is off and the IR illuminator is on, which reduces light pollution efficiently.
SMD Plus
With intelligent algorithm, Dahua Smart Motion Detection technology can categorize the targets that trigger motion detection and filter the motion detection alarm triggered by non-concerned targets to realize effective and accurate alarm
Perimeter Protection
With deep learning algorithm, Dahua Perimeter Protection technology can recognize human and vehicle accurately. In restricted area (such as pedestrian area and vehicle area), the false alarms of intelligent detection based on target type (such as tripwire, intrusion) are largely reduced.
Smart H.265+ & Smart H.264+
With advanced scene-adaptive rate control algorithm, Dahua smart encoding technology realizes the higher encoding efficiency than H.265 and H.264, provides high-quality video, and reduces the cost of storage and transmission
Full-color
With high-performance sensor and large aperture lens, Dahua Full-color technology can display clear colorful image in the environment of ultra-low illuminance. With this photosensitivity technology, the camera can capture more available light, and display more colorful image details.
Cyber Security
Dahua network cameras employ a series of security technologies, including security authentication and authorization, access control protocols, trusted protection, encrypted transmission and encrypted storage. These technologies improve the camera's defense against external cyber threats and prevent malicious programs from compromising the device.
Protection (IP67, Wide Voltage)
"IP67: The camera passes a series of strict test on dust and soak. It has dust-proof function, and the enclosure can work normally after soaking in 1 m deep water for 30 minutes.
Wide voltage: The camera allows ±30% (for some power supplies) input voltage tolerance (wide voltage range), and it is widely applied to outdoor environment with instable voltage.
Εγγυήσεις - Επιστροφές: | |
Επιστροφή Χρημάτων: | Επισκευή - Αντικατάσταση: |
20 ημέρες | 36 μήνες |
SPECIFICATIONS | |
Camera | |
Image Sensor | 1/2.8" CMOS |
Max. Resolution | 1920 (H) × 1080 (V) |
ROM | 128 MB |
RAM | 128 MB |
Scanning System | Progressive |
Electronic Shutter Speed | Auto/Manual 1/3 s–1/100,000 s |
Min. Illumination | 0.002 Lux@F1.6 (Color, 30 IRE) 0.0002 Lux@F1.6 (B/W, 30 IRE) 0 Lux (Illuminator on) |
S/N Ratio | >56 dB |
Illumination Distance | up to 30 m (IR) up to 30 m (Warm light) |
Illuminator On/Off Control | Auto/ manual |
Illuminator Number | 1 (IR LED) 1 (Warm light) |
Pan/Tilt/Rotation Range | Pan: 0°–360° Tilt: 0°–90° Rotation: 0°–360° |
Lens | |
Lens Type | Fixed-focal |
Focal Length | 2.8 mm |
Lens Mount | M12 |
Max. Aperture | F1.6 |
Field of View | H: 107°; V: 56°; D: 127° |
Iris Control | Fixed |
Close Focus Distance | 0.7m |
DORI Distance | Detect: 43.9 m Observe: 17.5 m Recognize: 8.8 m Identify: 4.4 m |
Intelligence | |
IVS (Perimeter Protection) | Intrusion, tripwire (the two functions support the classification and accurate detection of vehicle and human) |
Smart Search | Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos |
Video | |
Video Compression | H.264H, H.265, H.264, H.264B, MJPEG (Only supported by the sub stream) |
Smart Codec | Smart H.265+ Smart H.264+ |
Video Frame Rate | Main stream: 1920 × 1080@ (1–25/30 fps) Sub stream: 704 × 576@ (1–25 fps)/704 × 480@ (1–30 fps) *The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity. |
Stream Capability | 2 streams |
Resolution | 1080p (1920 × 1080), 1.3M (1280 × 960), 720p (1280 × 720), D1 (704 × 576/704 × 480), VGA (640 × 480), CIF (352 × 288/352 × 240) |
BLC | Yes |
HLC | Yes |
Bit Rate Control | CBR/VBR |
Video Bit Rate | H.264: 32 kbps–6144 kbps H.265: 12 kbps–6144 kbps |
Day/Night | Auto(ICR)/Color/B/W |
WDR | 120 dB |
White Balance | Auto, natural, street lamp, outdoor, manual, regional custom |
Gain Control | Auto, manual |
Motion Detection | OFF/ON (4 areas, rectangular) |
Region of Interest (RoI) | Yes (4 areas) |
Noise Reduction | 3D NR |
Mirror | Yes |
Smart Illumination | Yes |
Privacy Masking | 4 areas |
Image Rotation | 0°/90°/180°/270° (Support with 1080p resolution and lower) |
Audio | |
Built-in MIC | Yes |
Audio Compression | G.711a, G.711Mu, PCM, G.726 |
Alarm | |
Alarm Event | No SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, motion detection, video tampering, tripwire, intrusion, SMD, voltage detection, security exception |
Network | |
Network Port | RJ-45 (10/100 Base-T) |
SDK and API | Yes |
Cyber Security | Configuration encryption, Trusted execution, Digest, Security logs, WSSE, Account lockout, syslog, Video encryption, 802.1x, IP/MAC filtering, HTTPS, Trusted upgrade, Trusted boot, Generation and importing of X.509 certification |
Network Protocol | IPv4, IPv6, HTTP, TCP, UDP, ARP, RTP, RTSP, RTCP, RTMP, SMTP, FTP, SFTP, DHCP, DNS, DDNS, NTP, Multicast, ICMP, IGMP |
Interoperability | ONVIF (Profile S/Profile T), CGI, P2P, Milestone |
User/Host | 6 (Total bandwidth: 36 M) |
Storage | FTP, SFTP, Micro SD card (support max. 256 GB) |
Browser | IE Chrome Firefox |
Management Software | DSS, DMSS |
Mobile Client | IOS, Android |
Certification | |
Certifications | CE-LVD: EN62368-1 CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU FCC: 47 CFR FCC Part 15, Subpart B UL/CUL: UL62368-1 & CAN/CSA C22.2 No. 62368-1-14 |
Power | |
Power Supply | 12 VDC/PoE (802.3af) |
Power Consumption | Basic: 1.6 W (12 VDC), 1.9 W (PoE) Max. (H.265 + intelligence + WDR + warm light): 3.8 W (12 VDC), 4.4 W (PoE) |
Environment | |
Operating Temperature | –40 °C to +60 °C |
Storage Temperature | –40 °C to +60 °C |
Operating Humidity | ≤95% |
Protection Grade | IP67 |
Structure | |
Casing | Metal |
Product Dimensions | 166.2 mm × 70 mm × 70 mm |
Net Weight | 0.48 kg |
Gross Weight | 0.59 kg |
