ΠΡΟΣΟΧΗ!!! Στην συσκευασία δεν συμπεριλαμβάνεται τροφοδοτικό!!!
Η τεχνολογία Dual-Light υποστηρίζεται μόνο εάν η κάμερα είναι συνδεδεμένη σε καταγραφικό τεχνολογίας AcuSense!
• High quality imaging with 2 MP, 1920×1080 resolution
• 2.8 mm, 3.6 mm fixed focal lens
• Up to 30 m IR distance for bright night imaging
• One port for four switchable signals (TVI/AHD/CVI/CVBS)
• Up to 20 m white light distance for bright night imaging
• High quality audio with audio over coaxial cable, built-in mic
• Water and dust resistant (IP67)
• Smart-Hybrid light, optimize your security with flexible lighting options
Εγγυήσεις - Επιστροφές: | |
Επιστροφή Χρημάτων: | Επισκευή - Αντικατάσταση: |
20 ημέρες | 36 μήνες |
Specifications | |
Camera | |
Image Sensor | 2 MP CMOS |
Max. Resolution | 1920 (H) × 1080 (V) |
Signal System | PAL/NTSC |
Min. illumination | 0.01 Lux@(F1.6, AGC ON), 0 Lux with IR |
Shutter Time | PAL: 1/25 s to 1/50, 000 s NTSC: 1/30 s to 1/50, 000 s |
Day & Night | ICR |
Angle Adjustment | Pan: 0 to 360°, Tilt: 0 to 90°, Rotation 0 to 360° |
Lens | |
Lens Type | 2.8 mm fixed lens |
Focal Length & FOV | horizontal FOV: 101°, vertical FOV: 56°, diagonal FOV: 118° |
Lens Mount | M12 |
Illuminator | |
Supplement Light Type | White Light,IR |
Supplement Light Range | IR : Up to 30 m White Light : Up to 20 m |
Image | |
Image Settings | Brightness, Sharpness, Smart IR |
Frame Rate | TVI: 1080P@30fps, 1080P@25fps AHD: 1080P@30fps, 1080P@25fps CVI: 1080P@30fps, 1080P@25fps CVBS: PAL/NTSC |
Day/Night Mode | Auto/Color/BW (Black and White) |
Wide Dynamic Range (WDR) | Digital WDR |
Image Enhancement | DWDR/BLC/HLC/Global |
White Balance | Auto/Manual |
AGC | Yes |
Interface | |
Video Output | Switchable TVI/AHD/CVI/CVBS |
Built-in Microphone | Yes |
General | |
Material | Metal |
Dimension | 138.8 mm × 60.9 mm × 57.9 mm |
Weight | Approx. 266 g |
Operating Condition | -40 °C to 60 °C , humidity: 90% or less (non-condensation) |
Communication | HIKVISION-C |
Language | English |
Power Supply | 12 VDC ± 25% *You are recommended to use one power adapter to supply the power for one camera. |
Consumption | Max. 3.3 W |
Approval | |
Protection | IP67 |
