ΠΡΟΣΟΧΗ!!! Στην συσκευασία δεν συμπεριλαμβάνεται τροφοδοτικό!!!
Η τεχνολογία Dual-Light υποστηρίζεται μόνο εάν η κάμερα είναι συνδεδεμένη σε καταγραφικό τεχνολογίας AcuSense!
• High quality imaging with 3K, 2960 × 1665 resolution
• 2.8 mm fixed focal lens
• Up to 30 m IR distance for bright night imaging
• Up to 20 m white light distance for bright night imaging
• One port for four switchable signals (TVI/AHD/CVI/CVBS)
• Water and dust resistant (IP67)
• High quality audio with audio over coaxial cable, built-in mic
• Smart-Hybrid light, optimize your security with flexible lighting options
Εγγυήσεις - Επιστροφές: | |
Επιστροφή Χρημάτων: | Επισκευή - Αντικατάσταση: |
20 ημέρες | 36 μήνες |
Specifications | |
Camera | |
Image Sensor | 3K CMOS |
Signal System | PAL/NTSC |
Max. Resolution | 2960 (H) × 1665 (V) |
Min. Illumination | 0.01 Lux @ (F2.0, AGC ON), 0 Lux with IR |
Shutter Time | PAL: 1/25 s to 1/50, 000 s; NTSC: 1/30 s to 1/50, 000 s |
Day & Night | ICR |
Angle Adjustment | Pan: 0 to 360°, Tilt: 0 to 90°, Rotation: 0 to 360° |
Illuminator | |
Lens Type | 2.8 mm fixed focal lens |
Focal Length & FOV | 2.8 mm, horizontal FOV: 104.9°, vertical FOV: 67.3°, diagonal FOV: 129.8° |
Lens Mount | M12 |
Image | |
Image Settings | Brightness, Sharpness, Smart IR |
Frame Rate | TVI: 3K@20 fps, 4 MP@25 fps/30 fps, 1080p@25 fps/30 fps AHD: 5 MP@20 fps, 4 MP@25 fps/30 fps CVI: 4 MP@25 fps/30 fps CVBS: PAL/NTSC |
Day/Night Mode | Auto/Color/BW (Black and White) |
Wide Dynamic Range (WDR) | Digital WDR |
Image Enhancement | DWDR/BLC/HLC/Global |
White Balance | Auto/Manual |
AGC | Yes |
Interface | |
Video Output | Switchable TVI/AHD/CVI/CVBS |
Built-in Microphone | Yes |
General | |
Material | Metal |
Dimension | 138.8 mm × Ø 70 mm |
Weight | Approx. 270 g |
Operating Condition | -40 °C to 60 °C humidity: 90% or less (non-condensation) |
Communication | HIKVISION-C |
Language | English |
Power Supply | 12 VDC ± 25% *You are recommended to use one power adapter to supply the power for one camera. |
Consumption | Max. 3.3 W |
Approval | |
Protection | IP67 |
