ΠΡΟΣΟΧΗ!!! Στην συσκευασία δεν συμπεριλαμβάνεται τροφοδοτικό!!!
• 5 MP high performance CMOS
• 2560 x 1944 resolution
• 2.8 mm fixed lens
• EXIR 2.0, smart IR, up to 30 m IR distance
• OSD menu, 3D DNR, 130 dB true WDR
• 4 in 1 video output (switchable TVI/AHD/CVI/CVBS)
• IP67
• Up the coax (HIKVISION-C)
Εγγυήσεις - Επιστροφές: | |
Επιστροφή Χρημάτων: | Επισκευή - Αντικατάσταση: |
20 ημέρες | 36 μήνες |
Specifications | |
Camera | |
Image Sensor | 5 megapixel progressive scan CMOS |
Signal System | PAL/NTSC |
Resolution | 2560 (H) x 1944 (V) |
Min. Illumination | Color: 0.003 Lux@(F1.2, AGC ON), 0 Lux with IR |
Frame Rate | TVI: 2 MP@25fps, 2 MP@30fps, 4 MP@25fps, 4 MP@30fps, 5 MP@20fps AHD: 4 MP@25fps, 4 MP@30fps, 5 MP@20fps CVI: 4 MP@25fps, 4 MP@30fps CVBS: PAL, NTSC |
Shutter Time | PAL: 1/25 s to 1/50,000 s NTSC: 1/30 s to 1/50,000 s |
Lens | 2.8 mm |
Horizontal Field of View | 98° |
Lens Mount | M12 |
Day & Night | IR cut filter |
Angle Adjustment (Bracket) | Pan: 0° to 360°, Tilt :0° to 75°, Rotate: 0° to 360° |
Synchronization | Internal synchronization |
WDR (Wide Dynamic Range) | ≥ 130 dB |
Menu | |
AGC | Yes |
Day/Night Mode | Auto/Color/BW (Black and White) |
White Balance | Auto/Manual |
BLC (Backlight Compensation) | Yes |
WDR | Yes |
3D DNR | Level 1 to 9 |
Privacy Mask | 4 programmable privacy masks |
Motion Detection | 4 programmable areas |
Language | English |
Functions | Brightness, Sharpness, 3D DNR, Mirror, Smart IR |
Interface | |
Video Output | 1 HD analog output |
Switch Button | TVI/AHD/CVI/CVBS |
General | |
Operating Conditions | -40 °C to 60 °C, humidity: 90% or less (non-condensing) |
Power Supply | 12 VDC ± 25% *You are recommended to use one power adapter to supply the power for one camera. |
Power Consumption | Max. 5.8 W |
Protection Level | IP67 |
Material | Metal |
IR Range | Up to 30 m |
Communication | Up the coax, Protocol: HIKVISION-C (TVI output) |
Dimensions | 90 mm x 79.37 mm |
Weight | Approx. 300 g |
