ΠΡΟΣΟΧΗ!!! Στην συσκευασία δεν συμπεριλαμβάνεται τροφοδοτικό!!!
• Accurate human and vehicle target classification and alarm, and face capture based on deep learning hardware and algorithm
• Face capture: automatic selection of best shot; up to 5 faces detected and captured at the same time
• Linked audible and visual alarm. Built-in microphone and speaker
• Up to 2560 × 1440 @ 30 fps
• Min. illumination: Color: 0.0005 Lux @ (F1.0, AGC ON); 0 Lux with white light
• 24/7 colorful imaging with low power consumption. Up to 30 m white light distance
• 120 dB WDR, 3D DNR, HLC
• IP66; PoE
Προσοχή! Βάσει της ισχύουσας Ελληνικής Νομοθεσίας, του Ε.Κ.Κ.Ζ.Σ. και των όσων προβλέπει το Π.Δ. 98/2017 η νόμιμη χρήση του προϊόντος αυτού στη ζώνη συχνοτήτων 2400 – 2483,5 MHz, προβλέπει μέγιστη ισχύ εκπομπής τα 100 mW e.i.r.p. Στην ισχύ αυτή συνυπολογίζεται η ισχύς εξόδου του πομπού και το κέρδος της κεραίας. Αρμόδια για την εποπτεία του φάσματος είναι η E.E.T.T. Το προϊόν αυτό είναι εφοδιασμένο με σήμα συμμόρφωσης CE βλ. Π.Δ. 98/2017 Το προϊόν αυτό προορίζεται για χρήση σε εξωτερικούς χώρους. |
Εγγυήσεις - Επιστροφές: | |
Επιστροφή Χρημάτων: | Επισκευή - Αντικατάσταση: |
20 ημέρες | 36 μήνες |
Specification | |
Camera | |
Image Sensor | 1/1.8" progressive scan CMOS |
Min. Illumination | Color: 0.0005 Lux @ (F1.0, AGC ON); 0 Lux with white light |
Shutter Speed | 1/1 to 1/30,000 s |
Day & Night | 24/7 colorful imaging |
Zoom | 16x digital |
Max. Resolution | 2560 × 1440 |
Lens | |
Focal Length | 4 mm |
FOV | Horizontal field of view: 88.7° Vertical field of view: 46.5° Diagonal field of view: 105.0° |
Aperture | F1.0 |
Illuminator | |
Supplement Light Type | White Light |
Supplement Light Range | White Light Distance: up to 30 m |
PTZ | |
Movement Range (Pan) | 350° |
Movement Range (Tilt) | 0°to 90° |
Pan Speed | Pan speed: configurable from 0.1°to 60°/s; preset speed: 60°/s |
Tilt Speed | Tilt speed: configurable from 0.1°to 50°/s, preset speed 50°/s |
Proportional Pan | Yes |
Presets | 300 |
Power-off Memory | Yes |
Park Action | Preset, patrol scan |
3D Positioning | Yes |
Preset Freezing | Yes |
Scheduled Task | Preset, patrol scan, dome reboot, dome adjust, aux output |
Video | |
Main Stream | 50 Hz: 25 fps (2560 × 1440, 1920 × 1080, 1280 × 960, 1280 × 720); 60 Hz: 30 fps (2560 × 1440, 1920 × 1080, 1280 × 960, 1280 × 720) |
Sub-Stream | 50 Hz: 25 fps (704 × 576, 640 × 480, 352 × 288); 60 Hz: 30 fps (704 × 480, 640 × 480, 352 × 240) |
Third Stream | 50Hz: 25 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 640 × 480, 352 × 288); 60Hz: 30 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 480, 640 × 480, 352 × 240) |
Video Compression | Main stream: H.265+/H.265/H.264+/H.264 Sub-stream: H.265/H.264/MJPEG Third stream: H.265/H.264/MJPEG |
Scalable Video Coding (SVC) | H.264 and H.265 encoding |
Region of Interest (ROI) | 8 fixed regions for each stream |
Audio | |
Audio Compression | G.711alaw, G.711ulaw, G.722.1, G.726, MP2L2, AAC, PCM |
Environment Noise Filtering | Yes |
Network | |
Network Storage | NAS (NFS, SMB/ CIFS) |
Protocols | IPv4/IPv6, HTTP, HTTPS, QoS, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP/IP, UDP, IGMP, ICMP, DHCP, PPPoE, Bonjour, Websocket, Websockets |
API | ISAPI, Hikvision SDK, Hik-Connect, Open Network Video Interface (Profile S, Profile G, Profile T), ISUP |
Simultaneous Live View | Up to 20 channels |
User/Host | Up to 32 users. 3 levels: Administrator, Operator and User |
Security | Authenticated username and password, MAC address binding, HTTPS encryption, 802.1X authenticated access, IP address filter |
Web Browser | IE 10+, Chrome 57+, Firefox 52+, Safari 12+ |
Client | iVMS-4200, Hik-Connect *Wi-Fi connection with Hik-Connect directly is not possible |
Wireless (Wi-Fi) | |
Wi-Fi Protocols |
IEEE802.11b, 802.11g, 802.11n |
Frequency Range | 2.4 GHz -2.4835 GHz |
Channel Bandwidth | 20/40 MHz |
Modulation | 802.11b: CCK, DQPSK, DBPSK 802.11g: OFDM/64-QAM, 16-QAM, QPSK, BPSK 802.11n: OFDM/64-QAM, 16-QAM, QPSK, BPSK |
Encryption Mode | 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK, WPS |
Transfer Rate | 11b: 11 Mbps, 11g: 54 Mbps, 11n: up to 150 Mbps |
Wireless Range | Up to 50 m |
Image | |
Day/Night Switch | Day, night, auto, scheduled-switch |
Image Enhancement | BLC, HLC, 3D DNR |
Wide Dynamic Range (WDR) | 120 dB WDR |
Defog | Digital defog |
Regional Exposure | Yes |
Image Settings | Saturation, brightness, contrast, sharpness, gain, and white balance adjustable by client software or web browser |
Image Parameters Switch | Yes |
Privacy Mask | Up to 24 masks (8 masks for each scene) |
SNR | >52 dB |
Interface | |
Built-in Speaker | 1 built-in speaker |
Power Output | 12 VDC; < 60 mA |
Ethernet Interface | 1 RJ45 10 M/100 M Ethernet interface; PoE (802.3at) |
On-board Storage | Built-in memory card slot, support MicroSD/SDHC/SDXC, up to 512 GB |
Alarm | 1 input, 1 output |
Audio | 1 input (line in), max. input amplitude: 2-2.4 vpp, input impedance: 1 KΩ ± 10%; 1 output (line out), line level, output impedance: 600 Ω RS-4851 RS-485 (Half duplex, HIKVISION, Pelco-P, Pelco-D, self-adaptive) |
RS-485 | 1 RS-485 (Half duplex, HIKVISION, Pelco-P, Pelco-D, self-adaptive) |
Reset | Yes |
Event | |
Basic Event | Video tampering alarm, motion detection, alarm input, alarm output, exception |
Smart Event | Line crossing detection, region entrance detection, unattended baggage detection, object removal detection, intrusion detection, region exiting detection, audio exception detection |
Alarm Linkage | Preset, memory card video recording, alarm output, sending email, notify surveillance center, upload to FTP, audible warning, white light flashing |
Deep Learning Function | |
Face Capture | Detects up to 5 faces simultaneously. Supports detecting, capturing, grading, selecting of face in motion, and outputs the best face picture |
Perimeter Protection | Line crossing, intrusion, region entrance, region exiting Support alarm triggering by specified target types (human and vehicle) |
General | |
General Function | Mirror, password protection, watermark, IP address filter |
Power | 12 VDC, 3.33 A & PoE (802.3at), 42.5 to 57 VDC, 0.6 A Max. 16 W (including max. 4 W for white light) |
Operating Condition | Humidity: ≤ 90%, temperature: -30°C to 65°C |
Demist | Yes |
Dimension | 179.3 mm × 120 mm × 182 mm |
Weight | Approx. 1.125 kg |
Approval | |
Protection | IP66; 6000 V Lightning Protection, Surge Protection and Voltage Transient Protection |
