Next-gen 2K HD PoE ceiling camera with enhanced dynamic range and low-light performance.
Features:
• 2K HD, 30 FPS camera with a 5MP CMOS sensor
• Wide-angle view (102.4˚)
• Weatherproof IPX4-rated enclosure with IK08-rated vandal resistance
• Improved low-light performance and IR night vision up to 10m
• Improved dynamic range
Managed with the UniFi Protect application: Version 2.2.7 or 2.7.18 and later (web) / 1.10.0 and later (mobile)
Εγγυήσεις - Επιστροφές: | |
Επιστροφή Χρημάτων: | Επισκευή - Αντικατάσταση: |
20 ημέρες | 24 μήνες |
Mechanical | |
Dimensions | Ø109.2 x 64.5 mm |
Weight |
With mount: 390g |
Enclosure materials | Aluminum alloy, polycarbonate, hard-coated dome |
Mount materials | Polycarbonate, stainless steel |
Weatherproofing | IPX4 |
Resistance | IK08 |
Optics | |
Sensor | 5 MP CMOS sensor |
Lens | Fixed focal length |
View angle | H: 102.4°, V: 71.4°, D: 134.3° |
Night mode | Built-in IR LED illumination and IR cut lter |
Video | |
Compression | H.264, MJPEG |
Resolution | 2688 x 1512 (16:9) |
Maximum frame rate | 30 FPS |
Image settings | Color, brightness, sharpness, contrast, white balance, exposure control, 2DNR, 3DNR, NR by motion, masking, text overlay |
System | |
Processor | Dual-core Arm Cortex-A7 based chip |
Networking interface | 10/100 MbE RJ45 |
Max. power consumption | 5W |
Power method | PoE |
Supported voltage range | 37–57V DC |
Link/activity LED | R/G/B/W |
Button | Factory reset |
Mounting | Wall, ceiling mount |
Operating temperature | -20 to 40° C |
Operating humidity | 0 to 90% noncondensing |
Certifications | FCC, IC, CE |
Audio | |
Microphone | Yes (can be disabled in software) |
Speaker | Yes |
Software | |
Management application | UniFi Protect |
Mobile app | UniFi ProtectiOS and Android |
