• (48) Gigabit RJ45 Ports • (2) SFP+ Ports • (2) SFP Ports • (1) Serial Console Port • Non-Blocking Throughput: 70 Gbps • Switching Capacity: 140 Gbps • Forwarding Rate: 104.16 Mpps • Maximum Power Consumption: 750W • Supports POE+ IEEE 802.3at/af and 24V Passive PoE • Rackmountable |
Εγγυήσεις - Επιστροφές: | |
Επιστροφή Χρημάτων: | Επισκευή - Αντικατάσταση: |
20 ημέρες | 24 μήνες |
Specifications | |
Dimensions | 485 x 43.7 x 374.6 mm |
Weight | 6.5 kg |
Total Non-Blocking Throughput | 70 Gbps |
Switching Capacity | 140 Gbps |
Forwarding Rate | 104.16 Mpps |
Max. Power Consumption | Includes PoE Output: 750W Excludes PoE Output: 64W |
Power Method | 100-240VAC/50-60 Hz, Universal Input |
Power Supply | AC/DC, Internal, 750W DC |
LEDs Per Port | RJ45 Data Ports: PoE, Speed/Link/Activity SFP Data Ports: Speed/Link/Activity |
Networking Interfaces | (48) 10/100/1000 Mbps RJ45 Ethernet Ports (2) 1/10 Gbps SFP+ Ethernet Ports (2) 1 Gbps SFP Ethernet Ports |
Management Interface | (1) RJ45 Serial Port, Ethernet In/Out Band |
Certifications | CE, FCC, IC |
Rackmount | Yes, 1U High |
ESD/EMP Protection | Air: ±24 kV, Contact: ±24 kV |
Operating Temperature | -5 to 40° C |
Operating Humidity | 5 to 95% Noncondensing |
Shock and Vibration | ETSI300-019-1.4 Standard |
PoE Per Port | |
PoE Interfaces | POE+ IEEE 802.3af/at (Pins 1, 2+; 3, 6-) 24VDC Passive PoE (Pins 4, 5+; 7, 8-) |
Max. PoE+ Wattage per Port by PSE | 34.2W |
Voltage Range 802.3at Mode | 50-57V |
Max. Passive PoE Wattage per Port | 17W |
24V Passive PoE Voltage Range | 20-27V |
