• (48) Gigabit RJ45 Ports • (2) SFP+ Ports • (2) SFP Ports • (1) Serial Console Port • Non-Blocking Throughput: 70 Gbps • Switching Capacity: 140 Gbps • Forwarding Rate: 104.16 Mpps • Maximum Power Consumption: 56W • Rack- or Wall-Mountable • DC Input Option (Redundant or Stand-Alone) |
Εγγυήσεις - Επιστροφές: | |
Επιστροφή Χρημάτων: | Επισκευή - Αντικατάσταση: |
20 ημέρες | 24 μήνες |
Specifications | |
Dimensions | 443 x 43 x 286 mm |
Weight | Rack-Mount Brackets Included: 3.65 kg Rack-Mount Brackets Excluded: 3.56 kg |
Total Non-Blocking Throughput | 70 Gbps |
Switching Capacity | 140 Gbps |
Forwarding Rate | 104.16 Mpps |
Max. AC Power Consumption | 56W |
Power Method | AC: 100-240VAC/50-60 Hz, Universal Input DC: DC 56W, 25 to 16V, with 2.5 mm DC Power Inline Connector |
Power Supply | AC/DC, Internal, 56W DC |
LEDs Per Port Serial Console Port RJ45 Data Ports SFP+/SFP Data Ports |
N/A Speed/Link/Activity Speed/Link/Activity |
Networking Interfaces | (48) 10/100/1000 Mbps RJ45 Ethernet Ports (2) 1/10 Gbps SFP+ Ethernet Ports (2) 1 Gbps SFP Ethernet Ports |
Management Interface | (1) RJ45 Serial Port, Ethernet In/Out Band |
Certifications | CE, FCC, IC |
Rackmount | Yes, 1U High |
ESD/EMP Protection | Air: ±24 kV, Contact: ±24 kV |
Operating Temperature | -5 to 40° C |
Operating Humidity | 5 to 95% Noncondensing |
Shock and Vibration | ETSI300-019-1.4 Standard |
