*When powered with the included AC/DC adapter.
**When enclosed in the UISP Box Plus (sold separately).
Εγγυήσεις - Επιστροφές: | |
Επιστροφή Χρημάτων: | Επισκευή - Αντικατάσταση: |
20 ημέρες | 24 μήνες |
Specifications | |
Dimensions | 210.4 x 170.2 x 43.7 mm |
Weight | 175 kg |
Enclosure material | SGCC steel, polycarbonate/acrylonitrile butadiene styrene |
Hardware | |
Processor | Dual-core ARM®v8 Cortex®-A55 at 1.4 GHz |
Memory | 1 GB DDR4 |
Onboard flash storage | 256 MB NAND |
Networking interface | (4) 1/2.5 GbE RJ45 LAN ports (4) 1/10G SFP+ ports |
Management interface | Ethernet In-band Bluetooth |
Total non-blocking throughput | 50 Gbps |
Switching capacity | 100 Gbps |
Forwarding rate | 74.4 Mpps |
Power Method | (1) External AC/DC adapter (1) Power TransPort DC input 27V DC, 7.04A |
Power Supply | 27V DC, 7.04A power adapter (included) |
Supported voltage range | 24 - 28VDC |
Max. power consumption | 25W (Excluding PoE output.) |
ESD/EMP protection | Air: ± 15 kV, contact: ± 8 kV |
Operating temperature | -10 to 50° C |
Operating humidity | 5 to 95% non-condensing |
Certifications | CE,FCC,IC |
PoE | |
PoE interface | (8) 27V passive PoE: 2-pair (pins 4, 5+/7, 8-) or 4-pair (pins 1, 2, 4, 5+/3, 6, 7, 8-) |
Max. Passive PoE wattage per port | 30W/27VDC |
Passive PoE voltage range | 27VDC |
LEDs | |
System | Status |
RJ45 data ports | PoE, Speed/Link/Activity |
SFP data ports | Link/activity |
