The Ubiquiti USW-Pro-8-PoE is a new switch that offers up to 6 POE/POE+ ports capable of delivering up to 30 W, as well as 2 POE++ ports that can deliver up to 60 W. The total maximum output power is 120 W. The switch has 2 SFP+ ports with speeds up to 10 Gbps, which is ideal for transferring even larger files. On the front of the switch you will find a touch control panel with AR settings as well. The switch can also be mounted on the wall with the appropriate bracket.
Key Features:
• Support new POE++
• High speed SFP+ ports with 10 Gbps
• Support L3
• Maximum output power 120W for POE
• Can be mounted on the wall
Εγγυήσεις - Επιστροφές: | |
Επιστροφή Χρημάτων: | Επισκευή - Αντικατάσταση: |
20 ημέρες | 24 μήνες |
Mechanical | |
Dimensions | 200 x 248 x 44 mm |
Weight | 2.1 kg |
Enclosure materials | Plastic, metal |
Mount material | Plastic |
Hardware | |
Management interface | Ethernet In-Band |
Networking interface | (8) GbE RJ45 ports (2) 10 Gbps SFP+ ports |
PoE interface | (6) PoE/PoE+ (Pins 1, 2+; 3, 6-) (2) 60W PoE++ (Pair A 1, 2+; 3, 6-) (Pair B 4, 5+; 7, 8-) |
Total non-blocking throughput | 28 Gbps |
Switching capacity | 56 Gbps |
Power method | Universal input, 100—240V AC, max. 2A |
Power supply | AC/DC, internal |
Supported voltage range | 100—240V AC |
Max. power consumption | 30W (Excluding PoE output) |
Total available PoE | 120W |
Max. PoE wattage per port by PSE | PoE: 15W PoE+: 30W PoE++: 60W |
Voltage range PoE mode | PoE: 44—57V PoE+: 50—57V PoE++: 50—57V |
LCM display | (1) 1.3" touchscreen |
LEDs | RJ45 ports: link/activity |
Button | Factory reset |
Operating temperature | -5 to 45° C |
Operating humidity | 10 to 90% noncondensing |
Certifications | CE, FCC, IC |
Application Requirements | |
UniFi Network | Version 7.5.176 and later |
