Dual-WAN security gateway designed to protect medium to large-sized networks with enterprise-class firewall configuration and threat management features. The UniFi Next-generation Gateway Pro (UXG Pro) is a powerful security gateway that delivers a versatile networking interface and enterprise-class threat management functionality to medium to large-sized networks. The UXG Pro is equipped with (2) WAN ports (GbE RJ45 and 10G SFP+) that provide failover support, as well as (2) LAN ports (GbE RJ45 and 10G SFP+) to provide the high-speed connectivity needed to support the most bandwidth-intensive applications. It also excels as a complete network security solution, offering a full suite of threat mitigation features, including deep packet inspection (DPI), intrusion detection and prevention systems (IDS/IPS), and layered firewall configuration. The UXG Pro can be paired with a Cloud Key Gen2 Plus to create a highly powerful and secure deployment that can be fully managed with the UniFi Network application (web/mobile).
Features:
• 1.7 GHz quad-core processor
• (2) WAN ports (GbE RJ45 and 10G SFP+) with failover support
• (2) LAN ports (GbE RJ45 and 10G SFP+)
• Enterprise-class DPI, IPS/IDS, and layered firewall configuration
• Power redundancy when connected to the UniFi SmartPower RPS (sold separately)
• SmartPower outlet (200~240VAC/1.25A) for an external modem
• 1U-sized, rack-mountable device
Works with the UniFi Network Application:
• Centrally manage multiple networks from an intuitive interface
• Enjoy real-time device insights and deep configuration options
• Upgrade device firmware remotely
• Manage network users and guests with ease
• Personalize the design, architecture, and privacy of guest hotspots
• Set up devices quickly and manage them on the go with a powerful mobile app
Εγγυήσεις - Επιστροφές: | |
Επιστροφή Χρημάτων: | Επισκευή - Αντικατάσταση: |
20 ημέρες | 24 μήνες |
Specifications | |
Dimensions | 442.4 x 43.7 x 285.6 mm |
Weight | 3.42Kg |
Enclosure materials | Front panel: aluminum CNC Top cover/base: SGCC steel |
Hardware | |
Processor | Quad-core ARM Cortex-A57 at 1.7 GHz |
Memory information | 2 GB DDR4 |
Management interface | Ethernet |
Networking interface |
LAN: (1) 1 GbE RJ45 port (1) 10G SFP+ port WAN: (1) 1 GbE RJ45 port (1) 10G SFP+ port |
LCM display | (1) 1.3" touchscreen Bootup animation: bootup in progress Firmware upgrade icon: firmware upgrading |
Button | Factory reset |
Power method | US: (1) Universal AC input, 125VAC, 2.7A max., 60 Hz (1) RPS DC input, 11.5VDC, 2.87A Worldwide: (1) Universal AC input, 200-240VAC, 1.7A max., 50/60 Hz (1) RPS DC input, 11.5VDC, 2.87A |
Power Supply | AC/DC, internal, 50W |
Max.power consumption | 30W |
ESD/EMP protection | Air: ± 15 kV, contact: ± 8 kV |
Operating temperature | -10 to 40° C (14 to 104° F) |
Operating humidity | 5 - 95% noncondensing |
Certifications | CE, FCC, IC |
LEDs | |
AC outlet/ RPS | Blue |
Ethernet | Green/amber |
SFP+ | White/green |
