• Built-in audible beeper
• RS-485 and Wiegand (W26/ W34) protocol
• Tamper-proof alarm
• Supports reading EM card (Frequency: 125 KHz) (DS-K1102AE/DS-K1102AEK/DS-1102AEM)
• Supports reading Mifare card (Frequency: 13.56 MHz). (DS-K1102AM/DS-K1102AMK/DS-K1102AEMK)
Warranties - Returns: | |
Money Return: | Repair - Replacement: |
20 days | 36 months |
Specifications | |
System | |
Processor | 32 bit |
Audio | |
Audio alert | Beeper |
Authentication | |
Card Reading Frequency | DS-K1102AE/DS-K1102AEK/DS-K1102AEM/DS-K1102AEMK: 125 KHzDS-K1102AM/DS-K1102AMK/DS-K1102AEM/DS-K1102AEMK: 13.56 MHz |
Card Reading Distance | ≤ 50 mm (1.97") |
Function | |
ID Settings | via DIP switch |
General | |
Keypad | DS-K1102AE/DS-K1102AM/DS-K1102AEM: No KeypadDS-K1102AEK/DS-K1102AMK/DS-K1102AEMK: Keypad with 12 keys (0 to 9, *, #) |
Indicator | Power indicator; Status LED indicator |
Power Supply | 12 VDC, 500 mA, 2 W |
Working Temperature | -20°C to 65°C |
Working Humidity | 10% to 90% (Non condensing) |
Dimensions | 121 mm × 86.5 mm × 14 mm |
Protective Level | IP64 |
Weight | ≤ 0.14 kg |
Installation | Applied for 86 & 120 gang box |
Buzzer | Beeper |
