SkyHawk
SkyHawk™ leverages Seagate's extensive experience in designing drives purpose-built for surveillance applications.

Key Advantages
ImagePerfect™ firmware is designed to ensure seamless video footage capture in 24x7 surveillance workloads¹ that record video from 64 HD cameras.

SkyHawk Health Management actively helps protect your surveillance storage by focusing on prevention, intervention, and recovery options.² Included is RAID RapidRebuild™, which provides 3× faster volume rebuilds over traditional RAID rebuilds.

Unparalleled data protection with included 3-year Rescue Data Recovery Services plan, helping protect important video data with Seagate's in-house data recovery services.

RV sensors built in allow drives to maintain performance in multi-bay systems, giving customers the flexibility to scale their systems when more storage is needed.

ATA streaming support enables recordings from up to 64 HD cameras for smooth, uninterrupted footage

Lower power consumption means a reduction in heat emissions, which improves reliability in surveillance solutions. Tarnish-resistant components help protect drive from environmental elements, increasing field reliability.

¹ SkyHawk surveillance drives are designed for always-on workloads of 180 TB/year. For higher transaction workloads, see Seagate’s enterprise-class drive offerings.
² Contact your Seagate sales representative for further information.

Warranties - Returns:
Money Return:	Repair - Replacement:
20 days	36 months

Specifications
SkyHawk™ Health Management Included	Yes
Interface	SATA 6Gb/s
Recording Technology	CMR
Drive Design	Air
Features and Performance
Drive Bays Supported	Up to 16
Cameras Supported	Up to 64
RV Sensors	Yes
Max Sustained Transfer Rate OD (MB/s)	180MB/s
Cache (MB)	256
Reliability/Data Integrity
Tarnish Resistan	Yes
Load/Unload Cycles	600,000
Nonrecoverable Read Errors Rate, Max	1 per 10E14
Power-On Hours per year	8760
Workload Rate Limit (WRL) ¹	180
Mean Time Between Failures (MTBF) (hours)	1,000,000hr
Power Management
Startup Current, Typical (12V, A)	1.8
Average Operating Power (W)	3.7W
Idle Average (W)	2.5W
Standby Mode/Sleep Mode, Typical (W)	0.25/0.25
Voltage Tolerance (5V)	±5%
Voltage Tolerance (12V)	±10%
Environmental/Temperature
Operating (ambient, min °C)	0
Operating (drive reported, max °C) ⁴	65
Nonoperating (ambient, min °C)	-40
Physical
Height (mm, max)	20.20mm
Width (mm, max)	101.6mm
Depth (mm, max)	146.99mm
Weight (g, typical)	630g

¹ SkyHawk surveillance drives are designed for always-on workloads of 180TB/year. For higher transaction workloads, see Seagate’s enterprise-class drive offerings.
⁴ Seagate does not recommend operating at sustained extreme temperatures. Operating at higher temperatures will reduce useful life of the products

Datasheet
