TP-LINK MC210CS V7 Gigabit Single-Mode Media Converter
Product Code:
MC210CS
Manufacturer Tp-link
Sales price:
39,90 €(Includes 24% VAT)
Sales price without TAX:32,18 €
Product Availability:
Show Shipping Cost:
- Description
- Specifications
- Downloads
- Reviews
TP-LINK MC210CS V7 Gigabit Single-Mode Media Converter
| • 1× 10/100/1000Mbps Auto-Negotiation RJ45 port supporting Auto-MDI/MDIX • Auto-negotiation of Half-Duplex / Full-Duplex transfer mode • Complies with IEEE 802.3ab and IEEE 802.3z • Extends fiber distance up to 20km |
What This Product Does
The MC210CS is a media converter designed to convert 1000BASE-LX fiber to 1000Base-T copper media or vice versa. Designed under IEEE802.3ab 1000Base-T and IEEE802.3z 1000Base-LX standards, the MC210CS is designed for use with single-mode fiber cable utilizing the SC-Type connector. The MC210CS supports longwave (LX) laser specification at a full wire speed forwarding rate. It works at 1310nm on both transmitting and receiving data.
Other features of this module include the ability to be used as a stand alone device (no chassis required) or with TP-Link´s MC1400 chassis, Auto MDI/MDI-X for TX port, and front panel status LEDs. The MC210CS will transmit at extended fiber optic distances utilizing single-mode fiber up to 20 kilometers.
| Warranties - Returns: | |
| Money Return: | Repair - Replacement: |
| 20 days | 60 months |
| Specifications | |
| Standards | IEEE 802.3, IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3x |
| Interface |
2 1000Mbps SC/UPC ports
1 10/100/1000Mbps RJ45 port
|
|
Ethernet Cable
(Twisted Pair)
|
10BASE-T: 2-pair UTP/STP of Cat. 3,4,5 (≤100 m)
100BASE-TX: 4-pair UTP/STP of Cat. 5e or above (≤100 m)
1000BASE-T: 4-pair UTP/STP of Cat. 5e or above (≤100 m)
|
| Fiber Type | 9/125 μm single-mode fiber (≤20 km) |
| Wave Length | 1310nm |
|
Dimensions
(W × D × H)
|
94.5 × 73.0 × 27.0 mm |
| Power Supply | 9V/0.6A |
|
Max Power
Consumption
|
1.8 W |
| Certification | CE, FCC, RoHS |
| Environmental and Physical Specifications | |
| Operating Temperature |
0̊C to 50̊ C
|
| Storage Temperature | -40 ̊C to 70 ̊C |
| Operating Humidity | 10% to 90% RH non-condensing |
| Storage Humidity | 5% to 90% RH non-condensing |
There are yet no reviews for this product.
