MaxLink MAXPIDIN60 PoE injector, 12-48VDC, 802.3af/at/bt, 55V, 1.1A, 60W, 1Gbit
MaxLink MAXPIDIN60 is an active DIN rail mounting PoE injector with DC power input from 12 to 48 V and built in power converter. The output of this power supply is 1Gbit port with support of the 802.3af/at (55 V) which is dedicated for Wi-Fi, VoIP, or wireless links. The PoE's distribution is on the pins 1, 2, 7, 8 (-), 3, 4, 5, 6 (+). The second 1Gbit LAN port is used for data input. Total power is 60 W. The main advantage of this power supply is 6kV (10/700us) overvoltage protection. This PoE injector is best for using in the places where you already have a main power supply such as the solar panels or a high voltage power supply.
| Warranties - Returns: | |
| Money Return: | Repair - Replacement: |
| 20 days | 24 months |
| Specifications | |
| PoE Out standards | 802.3af, 802.3at, 802.3bt |
| PoE Out ports | 1 |
| LED indication | Yes |
| Pin powering | 1,2,7,8 (-), 3,4,5,6 (+) |
| Output Voltage | 55V |
| Output Power / 1port | 60W |
| Ethernet speed | 10/100/1000 Mbps |
| Gigabit LAN | Yes |
| Protection class | IP40 |
| Operating temperature | -40 up to 65°C |
| Weight | 400g |
| Depth | 95mm |
| Width | 35mm |
| Height | 135mm |
| Package Contents | MAXPIDIN60 1x User Manual Ground lug Wire: 16AWG |
