Ubiquiti U-POE++ PoE Gigabit PoE Injector, 48V/1.25A

Product Code:
U-POE++
Manufacturer Ubiquiti
Sales price: 37,00 €(Includes 24% VAT)
Sales price without TAX:29,84 €
Product Availability:

Show Shipping Cost:
  • Description
  • Specifications
  • Downloads
  • Reviews
Ubiquiti U-POE++ PoE Gigabit PoE Injector, 48V/1.25A

U-POE++ is a high-quality Gigabit PoE injector with one PoE output port for powering devices with voltage level of 48V with a maximum output power of 60W, which is sufficient for the energy-intensive devices. The power supply is conducted on all the wires 1,2,4.5 (+) and 3,6,7.8 (-). Of course, the source also includes protection against electrical overvoltage. A 3-pin power cord is included.

• Delivers up to 60W of PoE+
• Even more power for UA Hub, G4 PTZ, and other PoE++ devices
• Surge, peak pulse, and overcurrent protection
• Contains RJ45 data input, AC cable with earth ground, and PoE++ output
• LED indicator for status monitoring

Warranties - Returns:
Money Return: Repair - Replacement:
20 days 24 months
Specifications
Dimensions 106 x 63 x 34 mm
Weight 210 g
Output Voltage 48V DC @ 1.25A
LAN Activity Indicator No
Gigabit LAN Port Yes
Remote Reset Capability No
Reset Button No
Rated Voltage 100-240VAC @ 50/60Hz
Input Current 1.3A @ 120V AC
0.75A @ 230V AC
Inrush Current <100A peak @ 120V AC
<200A peak @ 230V AC
Efficiency 85+%
Output Ripple 1% max.
Switching Frequency 65 kHz
Line Regulation ≤ 1%
Load Regulation ≤ 3%
2-pair powering No
4-pair powering Pins 1, 2, 4, 5 (+) and 3, 6, 7, 8 (-)
AC Connector IEC-320 C6
Data IN / POE RJ45 Shielded Socket
Surge Protection Difference and Common Mode
Clamping Protection 11V Data, 60V Power
Max. Surge Discharge 1500A (8/20 µs) Power
Peak Pulse Current 36A (10/1000 µs) Data
Shunt capacitance <5 pF data
Response time <1 ns
Power method Universal AC input, 100—240V AC, 50/60Hz, (48V@ 1.25A)
Power supply AC/DC
Supported voltage range 100—240V AC
Max. PoE+ wattage per port by PSE 60W
Operating temperature 0 to 40° C
Storage temperature -30 to 70°C
Operating humidity 10 to 95% noncondensing
Certifications CE, FCC, IC, UL, UKCA, KC, CCC, KC, RoHS
