• 16 10/100Mbps Auto-Negotiation RJ45 ports, Supports Auto MDI / MDIX
• Green Ethernet technology saves power consumption
• IEEE 802.3x flow control provides reliable data transfer
• Plastic case, desktop or wall-mounting design
• Plug and play, no configuration required

What This Product Does
The TL-SF1016D Fast Ethernet Switch is designed for SOHO (Small Office/Home Office) or workgroup users. All 16 ports support auto MDI/MDIX, no need to worry about the cable type, simply plug and play. Moreover, with the innovative energy-efficient technology, the TL-SF1016D can save the power consumption and most of the packaging material can be recycled, making it an eco-friendly solution for your business network.

High Performance
TL-SF1016D Fast Ethernet Switch provides 16 10/100Mbps Auto-Negotiation RJ45 ports. All ports support Auto MDI/MDIX function, eliminating the need for crossover cables or Uplink ports. And IEEE 802.3x flow control for Full Duplex mode and backpressure for Half Duplex mode alleviate the traffic congestion and make TL-SF1016D work reliably.

TP-LINK Green Technology
This new generation TL-SF1016D Fast Ethernet Switch features the latest innovative energy-efficient technologies that can greatly expand your network capacity with much less power. It automatically adjusts power consumption according to the link status and cable length to limit the carbon footprint of your network.
It also complies with the EU’S RoHS, prohibiting the use of certain hazardous materials. Besides, most of the packaging material can be recycled.

Easy to Use
The auto features of this switch make installation plug and play and hassle-free. No configuring is required. Auto MDI/MDIX eliminates the need for crossover cables. Auto-negotiation on each port senses the link speed of a network device (10, 100 Mbps) and intelligently adjusts for compatibility and optimal performance.

Warranties - Returns:
Money Return:	Repair - Replacement:
20 days	36 months

SPECIFICATIONS
Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3x
Protocol	CSMA/CD
Interface	16 10/100Mbps RJ45 Ports AUTO Negotiation, AUTO MDI/MDIX
Switching Features	Half and Full Duplex MAC Address Learning 3.2 Gbps Switching Capacity
Forwarding Rates	10BASE-T: 14880pps/port 100BASE-TX: 148800pps/port
Data Rates	10/100Mbps at Half Duplex 20/200Mbps at Full Duplex
LEDs	Power, Ethernet Ports(1-16)
Transfer Method	Store and Forward
Power Supply	External Power Adapter (Output: 5 V/0.6 A)
Certifications	CE, FCC, RoHS
Dimensions	200 x 142 x 40 mm
Operating Temperature	0°C to 40 °C (32 °F to 104°F )
Storage Temperature	-40 °C to 60 °C (-40 °F to 140°F )
Operating Humidity	10% to 90% non-condensing
Storage Humidity	5% to 90% non-condensing
Package Contents	16-Port 10/100Mbps Desktop Switch TL-SF1016D Power Adapter User Guide
