• 5 Gigabit Auto-Negotiation RJ45 ports, Supports Auto MDI / MDIX • Green Ethernet technology saves power consumption • IEEE 802.3x flow control provides reliable data transfer • Plastic case, desktop or wall-mounting design • Plug and play, no configuration required |
Warranties - Returns: | |
Money Return: | Repair - Replacement: |
20 days | 36 months |
HARDWARE FEATURES | |
Standards and Protocols | IEEE 802.3, IEEE 802.3i, IEEE 802.3u, IEEE802.3ab, IEEE 802.3x, IEEE 802.1p |
Interface | 5 10/100/1000Mbps RJ45 Ports, Auto Negotiation, Auto MDI/MDIX |
Transmission Method | Store and Forward |
Advanced Functions | Green Technology, 802.3x Flow Control, 802.1p/DSCP QoS |
Max Power Consumption | 3.1W |
Power Supply | External Power Adapter (Output: 5VDC / 0.6A) |
Certification | FCC, CE, RoHs |
Dimensions (W x D x H) | 140 × 88 × 23 mm |
Package Contents | 5-Port Gigabit Desktop Switch TL-SG1005D Power Adapter Installation Guide |
Environment | Operating Temperature: 0°C~40°C Storage Temperature: -40°C~60°C Operating Humidity: 10%~90%RH, non-condensing Storage Humidity: 5%~90%RH, non-condensing |
