• RE600X comes equipped with the latest wireless technology, Wi-Fi 6, for faster speeds, greater capacity, and reduced network congestion.
• Creates a Mesh network by connecting to a TP-Link OneMesh™ router for seamless whole-home coverage.
• Gigabit Ethernet Port – Provides faster-wired connections to smart TVs, computers and gaming consoles
• Intelligent Signal Light – Helps to determine the best location for optimal Wi-Fi coverage by indicating the signal strength in the current placement
• AP Mode – Creates a new Wi-Fi access point to enhance your wired network with Wi-Fi capability
• TP-LINK Tether App – Easily access and manage your network using any iOS or Android mobile device
• Ultimate Compatibility – Extends the range of any Wi-Fi router or wireless access point

Meet the next generation WiFi 6 with more capacity and data throughput
With WiFi 6, you will enjoy faster speeds, lower latency, and able to connect more devices. When comparing with the last-gen WiFi, WiFi 6 features 25% faster data throughput thanks to 1024-QAM.

AX1800 Dual Band WiFi Provides Strong Signals in Every Corner of Your Home
- 1201Mbps 5 GHz Band
- 574Mbps 2.4 GHz Band

TP-Link OneMesh™ Roaming Redefined
Stop searching around for full bars. OneMesh™ is a simple way to form a Mesh network with a single WiFi name for seamless whole-home coverage. Just connect RE600X to an OneMesh™ router.³

OFDMA
Increased Efficiency with OFDMA^5.OFDMA improves your wireless network with higher throughput, lower latency, and more efficient power consumption.

Beamforming
Boosted WiFi Coverage with Beamforming. Beamforming technology concentrates the WiFi signal towards your connected devices, providing better WiFi range and network performance.

Gigabit Ethernet for Reliable Connections
One Gigabit Ethernet port provides warp-speed wired connections for 4K HD streaming, lag-free gaming, and more.

Built-In Access Point Mode
RE600X is more than a wireless range extender. Simply plug an Ethernet cable into its Ethernet port, and easily turn your wired internet connection into a 2×2 MIMO dual band wireless access point.

Wide.Wider.Widest.
You can set the extender’s WiFi coverage depending on how large you want your WiFi area to be using the Tether app.

Control at Your Fingertips
Set up and manage your WiFi through the TP-Link Tether app from your phone (Android, iOS), including TP-Link routers and range extenders.

1. The product may not be compatible with routers or gateways with firmware that has been altered, is based on open source programs, or is non-standard or outdated.
2. The use of MU-MIMO requires clients to also support MU-MIMO.
3. Smart Roaming is designed for devices that support the 802.11k/v standard.

Caution! According to current Greek Legislation, of N.F.B.A.R. and the provisions of the P.D. 98/2017 the lawful use of this product in the frequency band 2400 – 2483,5 MHz, provides for a maximum transmit power of 100mW e.i.r.p.
At this maximum power the output power of the transmitter and the gain of the antenna are both taken into account. Responsible for spectrum surveillance is H.T.P.C.
This product is CE marked, P.D. 98/2017
This product is intended for indoor use.

Caution! According to current Greek Legislation, of N.F.B.A.R. and the provisions of the P.D. 98/2017 the lawful use of this product in the frequency band 5150 – 5250MHz and 5250 – 5350MHz, provides for a maximum transmit power of 200 mW e.i.r.p.
At this maximum power the output power of the transmitter and the gain of the antenna are both taken into account. Responsible for spectrum surveillance is H.T.P.C.
This product is CE marked, P.D. 98/2017
This product is intended for indoor use.

Warranties - Returns:
Money Return:	Repair - Replacement:
20 days	36 months

HARDWARE
Button	WPS Button, Reset Button
Port	1 Gigabit Ethernet Port
Power Consumption	11.2W
Dimensions(WxDxH)	78×36×149 mm
WIRELESS
Wireless Standards	IEEE 802.11a/n/ac/ax 5 GHz, IEEE 802.11b/g/n/ax 2.4 GHz
Frequency	2.4GHz and 5GHz
Signal Rate	574 Mbps at 2.4 GHz, 1201 Mbps at 5 GHz
Transmit Power	CE: 2.4 GHz ≤ 20dBm, 5 GHz ≤ 23dBm (5.15 GHz ~ 5.35 GHz), 5 GHz ≤ 30dBm (5.45 GHz ~ 5.75 GHz)
Reception Sensitivity	5 GHz: 11a 6Mbps: -97dBm, 11a 54Mbps: -78dBm 11ax HE20 MCS0: -97dBm, 11ax HE20 MCS11: -66dBm 11ax HE40 MCS0: -94dBm, 11ax HE40 MCS11: -63dBm 11ax HE80 MCS0: -91dBm, 11ax HE80 MCS11: -61dBm 2.4 GHz: 11g 6Mbps: -96dBm, 11g 54Mbps: -78dBm 11ax HE20 MCS0: -96dBm, 11ax HE20 MCS11: -65dBm 11ax HE40 MCS0: -93dBm, 11ax HE40 MCS11: -63dBm
Wireless Functions	Enable/Disable Wireless Radio, Wireless Statistics
Wireless Security	WPA, WPA2, WPA3
OTHERS
Certification	CE, RoHS
System Requirements	Microsoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 7, 8, 8.1, 10, MAC OS, NetWare, UNIX or Linux Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari 4.0, or other Java-enabled browser
Package Contents	Wi-Fi Range Extender RE600X Quick Installation Guide
